H4 OB
The next chapter begins with the H4. A re-imagined bowrider that brings a fresh sense of style and excitement to the category. Defined by its vertical bow stem, the H4 combines strength with a contemporary style, further proving that Four Winns is willing to break from tradition to create something bold and new.
LOA
23' 11"/7.3 m
Beam
8' 5"/2.54 m
Persons Capacity
13
people
/
10
CE
Fuel Capacity
52 gal/197 L
APPROX. WEIGHT
4200 lbs/1905 kg
GALLERY
SPECS
| Approx. Boat & Engine Weight | 4200 lbs | 1905 kg |
| Approx. Draft Down | 35" | 89 cm |
| Approx. Draft Up | 18" | 46 cm |
| Beam | 8' 5" | 2.54 m |
| Bridge Clearance | 4' | 1.2 m |
| Bridge Clearance w/ Arch or Tower | 6' 11" | 2.1 m |
| Deadrise | 18° | 18° |
| Fuel Capacity | 52 gal | 197 L |
| Height on Trailer w/Wakeboard Tower Dn | 8' 10" | 2.7 m |
| Height on Trailer w/Wakeboard Tower Up | 10' 1" | 3.1 m |
| L.O.A | 23' 11" | 7.3 m |
| Maximum Capacity | 2625 lbs | 1191 kg |
| Persons Capacity | 13 | 10 |
| Storage Length on Trailer | 28' 11" | 8.8 m |
| Total Height | 5' 6" | 1.7 m |
| Total height on Trailer | 7' 2" | 2.2 m |
| Trailer Weight Tandem Axle | 1271 lbs | 577 kg |
| Water Capacity | 12 gal | 45 L |
Hull Color
- Solid White
Stripe Color
- Stripe Crimson Red
Hull and Deck
- Anchor locker w/ lid, latch & tie off
- Bow & stern eyes, stainless steel
- Cleats, fixed, stainless steel
- Exterior color, all white
- Exterior gel accent stripe, choice of color
- Fiberglass stringer system
- Horn
- Ladder, stern, angled, deep-reach, hidden w/ wide steps
- Meets applicable USCG & Canadian regs; NMMA certified using ABYC stds.
- Navigation lights, LED
- Rub rail w/ stainless steel insert
- StableVee® hull Next Gen
- Swim platform, stern
- Thru-hull fittings, stainless steel
- Windlass w/rope, chain & anchor
- Windshield header, polished
- Windshield w/walk-thru, full-height, curved glass, exclusive design
- Winning edge owner protection plan
Cockpit
- Assist handle(s), stainless steel, vinyl wrapped
- Beverage holder(s), stainless steel
- Coaming pads w/ rich hand-fitted vinyl & comfort padding
- Cooler, carry-on
- Courtesy lights, Blue LED
- Fiberglass liner, skid-resistant, self-draining
- Interior color scheme, choice of color
- Port console, glove box
- Seating, bow cushions, hinged
- Seating, cockpit, U-shaped
- Seating, ComfortRide, flip-up bucket bolster(s)
- Ski locker, in-floor, w/ gas-assist hinged lid & mat
- Storage, aft, cockpit basement
- Storage, beneath sundeck, mesh bags
- Storage, bow & cockpit, beneath seats
- Storage, cockpit, sidewall storage w/ beverage holders
- Sundeck, aft w/ chaise lounge
- Trash receptacle(s)
- Upholstery, premium contoured vinyl w/ custom detailing
- Walk-thru transom
- Water intrusion management system
Entertainment
- Speakers, (4)
- Stereo, w/ AM/FM radio, Bluetooth®
- USB port(s)
Helm
- Dash, rich hand-wrapped vinyl, w/ custom detailing & LED accent lighting
- Depth sounder
- Emergency engine shut-off
- Instrumentation, helm: touch screen, integrated gauges and GPS speed
- Lighted switches, LED
- Phone charger/holder, wireless
- Steering wheel, deluxe, tilt
Engine / Systems / Drive
- Battery single w/ on-off switch
- Battery(ies)
- Bilge pump(s), automatic
- Hydraulic tilt steering
- Outlet, 12V
- Outlet, USB charge port(s)
- Wiring harness w/ sealed connectors and tin coating for corrosion resistance
Trailer
- Four Winns® custom-matched trailer w/ brakes, tandem axle
- Jack-stand, heavy-duty
- Self-centering bunks
- Submersible lighting, LED
- Swing-away tongue
- Wheels, aluminum
Power Options
- Mercury 200XL FourStroke DTS
Interior Color
- Cognac
